Digitrax PM42 Power Manager for 4 SubDistricts Used, Untested eBay

Pm42 Digitrax. Digitrax PM42 Power DCCWiki Note 3: The preferred configuration for programming the PM42 is by using a Digitrax DT series, or equivalent, throttle in conjunction with an active LocoNet. To use a PM42 with a Zephyr, the trip current of the PM42 should be lowered from the default of 3 amps to 1.5A

Note: The factory default setting on all PM42 OpSw's is "thrown" or "t" A 3 amp trip current will work for most boosters and lay- outs

Digitrax PM42 Quad Power Manager for 4 Independent Power SubDistricts

PM42 Quad Power Manager lets you use a single booster and divide its output into 4 power sub-districts for automatic reversing or to improve operation by preempting booster shutdown when a short circuit is detected by the PM42. When the inevitable happens and a train runs into a thrown switch, resulting in a short, the PM42 shuts down the track power in. Connect the PM42 to the Digitrax Zephyr with a standard LocoNet cable

Wiring. A 3 amp trip current will work for most boosters and lay- outs This is the current that all Digitrax boosters can provide briefly under fault conditions with ade- quate track wiring

Digitrax DCC PM42 card edge 44pin connectors 2pack eBay. Many Digitrax operators use the PM42 Power Manager, which provides protection to four power sub-districts Note 3: The preferred configuration for programming the PM42 is by using a Digitrax DT series, or equivalent, throttle in conjunction with an active LocoNet.
